Phoenixcontact CAPAROC PM EIP - Feed-in module 1393553 is a power module within the CAPAROC circuit breaker system, featuring basic characteristics such as being a device circuit breaker with 4 slots, Protection Class III, and Pollution Degree 2; in terms of electrical performance, it has an operating voltage range of 10V DC to 30V DC (with rated voltages of 12V DC and 24V DC), a nominal inlet total current of 45A DC, a rated over-voltage of 0.5kV, adopts an electronic breaking method, boasts an efficiency higher than 99%, a typical closed-circuit current of 46mA at 24V no-load, a typical power consumption of 1.1W at 24V no-load (and less than 4.5W at 40A), as well as MTBF values of 7242508.37 hours (25°C, 21% load), 3958056.77 hours (40°C, 34.25% load), and 764697.81 hours (60°C, full load); for interface functions, it supports EtherNet/IP communication, is equipped with function blocks and add-on instructions for the Studio 5000 EtherNet/IP engineering tool, and can exchange data with QUINT POWER via the system bus interface; in terms of connection details, the main circuit IN+ and IN- use push-in connections (requiring a wire stripping length of 18mm, connectable to AWG20-8 rigid conductors and 0.5mm²-16mm² flexible conductors), while the system communication part also adopts push-in connections (with an 8mm wire stripping length, compatible with 0.2mm²-1.5mm² rigid conductors, AWG24-16 conductors, and 0.2mm²-0.75mm² flexible conductors); additionally, it supports DIN-rail installation via CAPAROC current rails, features tool-free connection technology for easy quick startup and intuitive operation, and comes with remote control and remote signaling functions (capable of monitoring 24V power supplies), making it compatible with Industry 4.0.

Phoenixcontact CAPAROC PM EIP - Feed-in module 1393553
