It is fully compatible with the entire Datalogic Memor family, including Memor 11, 12/17, and 30/35.
It can detect all common RFID tags at a distance of up to 9 m. The 2128P reader has enhanced accuracy and lightning-fast RFID read/write speeds, capturing all tags within range simultaneously. It includes in-reader tag de-duplication software capable of handling more than 50,000 unique tags from over 1 million tag reads.
Equipped with sophisticated user feedback, motion sensors, and embedded accelerometers to provide highly configurable, in-depth "search and find" features.
Supports Bluetooth classic and Bluetooth low energy (BLE), operating in SPP or HID modes, and supports iApp2 for Apple iOS devices. A wired ePop-loq® system allows for secure connection between the PDA and reader, avoiding Bluetooth data transfer for extra security.
Equipped with a replaceable 2,300 mAh lithium-polymer battery.
Measures 158 x 98 x 170 mm (6.2 x 3.8 x 6.7 in). It is impact-resistant from 1.2 m drops onto concrete and features an IP52 protection rating.
Includes a micro SD socket, where a 32 GB micro SD card can store up to 500 million electronic product codes offline.
Supports the EPC Class 1 Gen 2 standard, with a frequency range of 865-868 MHz in Europe and 902-928 MHz in the United States.
| Parameter | Description |
|---|---|
| Maximum Output Power | 34 dBm EIRP |
| Nominal Read Range | Up to 9 m / 29.5 ft |
| Nominal Write Range | Up to 4 m / 13.1 ft |
| Field | 150-degree forward facing |
| Supported Standard | EPC Class 1 Gen 2 |
| Frequency Range | EU: 865 - 868 MHz; US: 902 - 928 MHz |
| Compatibility | Datalogic Memor 11, 12/17, 30/35, etc. |
| Battery | Replaceable 2,300 mAh lithium-polymer battery |
| Data Storage | Micro SD socket, a 32 GB micro SD card can store up to 500 million electronic product codes |
| Connectivity | Supports both Bluetooth classic and Bluetooth low energy (BLE), can be operated in serial port profile (SPP) or human interface device mode (HID), also supports iApp2 for Apple iOS devices; has a wired ePop-loq® system |
| Dimensions | 158 x 98 x 170 mm / 6.2 x 3.8 x 6.7 in (LxWxH) |
| Weight | 445 g / 15.7 oz (including battery) |
| Protection Level | IP52 |
The 2128P RFID Sled is fully compatible with the entire Datalogic Memor mobile computer family, including the Memor 11, Memor 12/17, and Memor 30/35.
It has a nominal read range of up to 9 meters (29.5 feet) and a nominal write range of up to 4 meters (13.1 feet), using a 150-degree forward-facing field.
The device features embedded de-duplication software that removes duplicate scans directly on the reader. This optimizes data flow by managing more than 50,000 unique tags from over 1 million tag reads.
It supports Bluetooth classic and Bluetooth Low Energy (BLE) in either SPP or HID modes, along with iApp2 for Apple iOS. Additionally, a secure wired ePop-loq® system allows for a direct data connection to the PDA to avoid Bluetooth data transfer.
It features an IP52 rating for resistance against dust and water, and is designed to withstand impacts from drops of up to 1.2 meters (3.9 feet) onto concrete.
Yes. It has a built-in micro SD slot that supports cards up to 32 GB. A 32 GB card can store up to 500 million electronic product codes offline, even without active USB or Bluetooth connections.
