Decoding Capability: Supports 1D/2D barcodes (including DPM, worn, smudged, or low-contrast codes) with a high first-read rate, ensuring accurate data capture even for challenging labels.
Scanning Speed & Range: Delivers ultra-fast decoding up to 120 frames per second (fps), with a working range of 25mm to 1000mm (varies by barcode density and resolution).
Resolution Options: Available in 1.3MP and 2MP sensor versions, adapting to different barcode sizes and distance requirements.
Rugged Design: Features an IP65 rating for dust and water resistance, and withstands vibration/shock in industrial settings. Its compact form factor (116 × 66 × 50mm) allows flexible mounting (panel, bracket, or conveyor-side).
Optical Features: Equipped with adaptive illumination (white LED + red aimer) and adjustable focus, ensuring visibility in dark, bright, or reflective environments.
Communication Interfaces: Supports Ethernet (TCP/IP), Serial (RS-232), USB, and discrete I/O, enabling seamless integration with PLCs, conveyors, and enterprise systems.
Software Compatibility: Works with Zebra's DataMan Setup Software and Link-OS, supporting remote configuration, monitoring, and firmware updates for centralized management.
Multi-Code & Advanced Modes: Offers multi-code reading (simultaneous capture of multiple barcodes) and trigger modes (continuous scan, external trigger, or motion detection), adapting to automated workflows.
Low Maintenance: Has no moving parts, reducing downtime and maintenance costs. It also supports easy lens replacement for different scanning scenarios.
Primarily used in manufacturing (production line tracking, component tracing), logistics (conveyor sorting, package scanning), and warehousing (automated inventory management).
Ideal for high-volume, continuous-operation environments where manual scanning is impractical, improving throughput and reducing human error.
| Category | Specifications |
|---|---|
| Product Model | ZEBRA FS42 Fixed Industrial Scanner |
| Scanning Capability | 1D/2D barcodes (supports DPM, worn, smudged, low-contrast codes); Multi-code reading function |
| Sensor Resolution | 1.3MP (standard); 2MP (optional) |
| Scanning Speed | Up to 120 frames per second (fps) |
| Working Range | 25mm - 1000mm (varies by barcode density and resolution) |
| Optical Features | Adaptive illumination (white LED + red aimer); Adjustable focus |
| Dimensions | 91.4mm x 64mm x 54mm |
| Protection Rating | IP65 (dust and water resistance) |
| Communication Interfaces | Ethernet (TCP/IP), Serial (RS-232), USB, Discrete I/O |
| Software Compatibility | DataMan Setup Software, Link-OS (supports remote configuration/monitoring/firmware updates) |
| Trigger Modes | Continuous scan, External trigger, Motion detection |
| Operational Design | No moving parts (low maintenance); Compact form factor for flexible mounting |
| Application Scenarios | Manufacturing (production line tracking), logistics (conveyor sorting), warehousing (automated inventory management) |
| Specification | FS42 2MP | FS42 5MP |
|---|---|---|
| Image Sensor Resolution | 2MP | 5MP |
| Core Scanning Capability | Supports 1D/2D barcodes & DPM codes; Accurately reads worn, low-contrast codes | Same as 2MP version (consistent decoding performance) |
| Dimensions (L x W x H) | 91.4mm x 64mm x 54mm | 91.4mm x 64mm x 54mm |
| Weight | 400g | 400g |
| Protection Rating | IP65/IP67 | IP65/IP67 |
| Maximum Frame Rate | Up to 60 fps | Up to 60 fps |
| Communication Interfaces | Ethernet, Serial (RS-232), USB, Discrete I/O | Same as 2MP version |
