The Kinco KC200 series universal vector frequency converter features comprehensive and reliable protection and performance optimisation capabilities.
Its protective functions encompass overcurrent suppression protection (continuously monitoring current and automatically limiting it below the overcurrent suppression threshold), overvoltage suppression protection (when no braking resistor is connected, automatically adjusting operating frequency or employing magnetic braking to prevent overvoltage protection triggering due to excessive bus voltage), undervoltage suppression protection (supporting uninterrupted operation during momentary power outages), and wave-by-wave current limiting protection (restricting current rise during abnormal events like sudden load changes or transient current spikes to prevent overcurrent shutdowns).
Additionally equipped with overvoltage and overcurrent fault protection, it detects input phase loss based on bus voltage fluctuations (requires certain load conditions), rapidly identifies output phase loss before and after operation, and swiftly recognises phase-to-phase short circuits and ground faults within 10 milliseconds prior to operation.
Further protection mechanisms address inverter module overheating, parameter self-learning failure, current detection faults, and SVC stall faults. Regarding thermal management, this series employs an independent air duct design positioned close to the IGBT power devices for efficient heat dissipation. Software incorporates an automatic carrier frequency reduction function based on temperature rise.
In application scenarios, the KC200 series is widely applicable for driving equipment in industries such as textiles, machine tools, packaging, and food processing, as well as for fans, pumps, and various automated production machinery.
| Item | Specification | |
|---|---|---|
| Input | Rated voltage, Rated frequency | 2S: Single phase 200V~240V 50Hz/60Hz; 4T/5T: Three phase 380V~480V 50Hz/60Hz |
| Allowable fluctuation range of voltage | -15% ~ 10% | |
| Allowable fluctuation range of frequency | ±5% | |
| Output | Output voltage | 0 ~ input voltage |
| Maximum output frequency | 600Hz | |
| Overload capacity | G type machine: 150% rated current for 60s, 180% rated current for 3s | |
| Main control performance | Motor control method | V/F control, Open loop vector control (SVC), Closed loop vector control (FVC) |
| Modulation mode | Space vector PWM modulation | |
| Maximum carrier frequency | 16.0kHz | |
| Speed control range | Open loop vector control: rated load 1:100; Closed loop vector control: rated load 1:1000 | |
| Steady speed accuracy | Open loop vector control: ±0.5% rated synchronous speed; Closed loop vector control: ±0.02% rated synchronous speed | |
| Starting torque | Open loop vector control: 150% rated torque at 0.5Hz; Closed loop vector control: 200% rated torque at 0Hz | |
| Torque response | Open loop vector control: < 20ms; Closed loop vector control: < 10ms | |
| Frequency accuracy | Digital setting: maximum frequency * ±0.01%; Simulation setting: Maximum frequency * ±0.2% | |
| Frequency resolution | Digital setting: 0.01Hz; Simulation setting: Maximum frequency * 0.05% | |
| Torque boost | Automatic torque boost; Manual torque is increased by 0.1% ~ 30.0% | |
| Protection function | Phase absence protection | Input phase loss protection, output phase loss protection |
| Over-voltage protection | The main circuit stops when the DC voltage is above 800V | |
| Low-voltage protection | The main circuit stops when the DC voltage is below 350V | |
| Overheat protection | Trigger protection when the AC drive bridge overheats | |
| Overload protection | Overload operation, to reach the overload time stop | |
| Over-current protection | Stop if the AC drive exceeds 2.5 times the rated current | |
| Short circuit protection | Output interphase short-circuit protection, output short-circuit protection to the ground | |
| Environment | Installation site | In the altitude area of more than 1000 meters, due to the thin air caused by the poor heat dissipation effect of the AC drive, it needs to be derated, and 1% derated for every 100m rise |
| Temperature, humidity | -10℃ ~ +50℃, +40℃ ~ +50℃ please use derated, 5%RH - 95%RH (no condensation) | |
| Vibration | Less than 5.9m/s² (0.6g) | |
| Storage temperature | -20℃ ~ +60℃ | |
| Protection grade | IP20 | |
| Installation Method | Wall mounted | |
