| Models | Characteristics |
|---|---|
| R&S®HMF2525 | 1 channel, frequency range to 25 MHz |
| R&S®HMF2550 | 1 channel, frequency range to 50 MHz |
| Waveforms - standard | sine, square, pulse, ramp, triangle |
| Waveforms - arbitrary waveforms | up to 256kSa |
| Waveforms - predefined waveforms | sine, square (50%), ramp (positive/negative), triangle (50%), noise (white/pink), cardinal sine, exponential (rise/fall) |
| Operation modes | continuous, modulate, sweep, burst |
| Modulation types | AM, FM, PM, FSK, PWM |
| Temperature stability | 1x 10-6 (+18°C to +28°C) |
| Aging (after one year) | ±1x 10-6 (+25°C) |
| Models | Frequency range |
|---|---|
| R&S®HMF2525 | 10 µHz to 25 MHz |
| R&S®HMF2550 | 10 µHz to 50 MHz |
The R&S®HMF series features a high 14-bit resolution, operating at 250 MSample/s for precise signal generation.
The R&S®HMF2525 covers a frequency range from 10 µHz to 25 MHz, while the R&S®HMF2550 operates from 10 µHz up to 50 MHz.
Yes, custom waveforms can be created using the included PC software and transferred to the device via the HO720 interface, or imported in CSV format via the front USB port.
The devices support several modulation types, including AM, FM, PM, FSK, and PWM.
The temperature stability is rated at 1x 10-6 within the temperature range of +18°C to +28°C.
The physical dimensions are 285 mm (width) x 75 mm (height) x 365 mm (depth), and the instrument weighs approximately 3.6 kg.
