Power, ergonomics, and adaptation to harsh working circumstances are all carefully considered in the engineering of Panasonic cordless impact tools, which provide complete solutions for professional users. With their extended runtime and nearly zero torque reaction to effectively reduce operator fatigue and risk, these tools not only guarantee a safe and productive work environment, but they also offer exceptional durability and cost-effectiveness. Brushless motors combined with hybrid switch designs nearly double tool lifespan, which significantly lowers long-term maintenance costs.
With their adaptable dual-voltage technology, they may be used with Panasonic lithium-ion batteries between 14.4V and 18V, providing a range of power options to meet a variety of task needs. The instruments' strong IP protection technology, which has earned IP56 certification for dependable water and dust resistance, guarantees steady, consistent functioning even in challenging circumstances. Because of these exceptional qualities, Panasonic cordless impact tools are the best option for the heavy equipment, construction, automotive, and recreational vehicle industries.
The EY75A7X has compact dimensions of 5-5/8" x 9-13/16" x 2-7/8" and weighs 3.96 lbs, while the EY75A8X measures 8-7/16" x 9-15/16" x 3-1/16" and weighs 5.7 lbs. Their relatively small size and lightweight construction make them easy to handle, even in tight or hard-to-reach spaces. The shape and grip pattern are carefully crafted to reduce operator fatigue during extended use, with the center of gravity optimized for comfortable handling.
These impact tools come with multiple operating modes. For example, the self-drilling screw mode starts at the highest speed to cut a hole, switches to high-impact mode to cut the initial thread, and then automatically transitions to a slower soft mode as the load reduces. This limits the potential of stripping threads, making it ideal for delicate fastening tasks.
| Model | EY75A7X | EY75A8X |
|---|---|---|
| Max Torque | 2478 in-lbs | 346 ft-lbs (4152 in-lbs) |
| Dimensions (without battery) | 5-5/8" x 9-13/16" x 2-7/8" (143mm x 241mm x 73mm) | 8-7/16" x 9-15/16" x 3-1/16" (214mm x 252mm x 78mm) |
| Weight (without battery) | Approx. 3.96 lbs (1.79kg) | No official data |
| Weight (with 18V 5.0Ah LJ-type battery) | -- | Approx. 1.8 kg |
| Weight (with 14.4V 5.0Ah LJ-type battery) | -- | Approx. 1.7 kg |
| Rotational Speed | High mode: 0 - 2,500 rpm (18V), 0 - 2,300 rpm (14.4V); Medium mode: 0 - 1,500 rpm; Low mode: 0 - 1,000 rpm | High mode: 0 - 2,500 rpm (18V), 0 - 2,300 rpm (14.4V); Medium mode: 0 - 1,500 rpm; Low mode: 0 - 1,000 rpm |
| Impact Rate | High mode: 0 - 3,100 times/minute; Medium mode: 0 - 2,900 times/minute; Low mode: 0 - 1,900 times/minute | High mode: 0 - 3,600 times/minute (18V), 0 - 3,400 times/minute (14.4V); Medium mode: 0 - 2,900 times/minute; Low mode: 0 - 1,900 times/minute |
| Chuck | 12.7mm with snap-ring pin method (C-type spring) | 12.7mm with snap-ring pin method (C-type spring) |
| Dual Voltage Compatibility | Yes, accepts 14.4V or 18V Panasonic Li-ion batteries | Yes, accepts 14.4V or 18V Panasonic Li-ion batteries |
| IP Rating | IP56 | IP56 |
| Special Features | Electronic speed control, electric brake, LED light, self-drilling screw mode | Electronic speed control, forward/reverse switch, strong/medium/weak impact force switch, mountaineering-buckle compatible hook, LED light |
Panasonic's Compact Cordless Impact Tools, the EY75A7X and EY75A8X, are powerhouses engineered with a focus on performance, ergonomics, and resilience in challenging work conditions.
