Basic coverage spans 2 Hz to 50 GHz, extendable to 110 GHz with Keysight Smart Mixers. The standard 510 MHz real-time analysis bandwidth fully captures wideband signals like 5G NR and Wi-Fi 7 without frequent instrument changes.
Features a 75 dB spur-free dynamic range for identifying weak signals in strong interference. Noise floor extension technology reduces the noise floor below -170 dBm/Hz, with frequency and power measurement accuracy reaching ±(0.01 Hz + 1 × 10⁻¹¹ × f₀) and ±0.15 dB (typical), respectively.
Supports 255 MHz gapless streaming transmission for extended recording of real-world signals. Standard memory is expandable to terabyte-level capacity, complemented by optional removable SSDs for secure and flexible data migration.
Built-in core measurements support AM/FM/PM analog modulation and QAM digital modulation analysis. Combined with specialized software, it enables applications such as radar signal analysis, communication spurious testing, and semiconductor device characterization.
| Specification Category | Details |
|---|---|
| Frequency Range |
- Base: 2 Hz to 50 GHz - Extended: Up to 110 GHz with compatible Keysight smart mixers (e.g., N9030A-M0x series) |
| Analysis Bandwidth |
- Standard: Up to 510 MHz - Gap-free Streaming: Up to 255 MHz |
| Dynamic Range | - Spurious-Free Dynamic Range (SFDR): Up to 75 dB |
| Noise Performance |
- Noise Floor: Below -170 dBm/Hz (with Noise Floor Extension, NFE technology) - Optional: Front-end low-noise amplifier (LNA) for enhanced weak signal detection |
| Measurement Uncertainty |
- Frequency Accuracy: ±(0.01 Hz + 1 × 10⁻¹¹ × f₀) (f₀ = measured frequency) - Power Accuracy: ±0.15 dB (typical value) |
| Real-Time Capabilities (Option) |
- Real-Time Spectrum Analysis (RTSA) Bandwidth: Up to 510 MHz - Capture Probability: 100% for microsecond-level transient signals |
| Data Handling |
- Storage: Configurable with large-capacity memory; expandable to terabyte (TB)-class solid-state drives (SSDs) - Optional: Removable SSD for data security and portability |
| Modulation Analysis Support |
- Analog: AM, FM, PM - Digital: QAM (up to 4096-QAM), PSK, FSK, etc. (supports 5G NR, Wi-Fi 7, satellite communications, etc.) |
| Trigger Functions |
- Supports multi-dimensional triggers: Power, Frequency, Pulse, Modulation Code, etc. - Customizable trigger thresholds for targeted signal capture |
| Physical Specifications |
- Dimensions (W × H × D): 314 mm × 130 mm × 165 mm (12.36 in × 5.12 in × 6.50 in) - Weight: 10–20 kg (varies by configuration) - Power: External AC power (no built-in battery) |
| Key Optional Features |
- Real-Time Spectrum Analysis (RTSA) - Front-end low-noise amplifier (LNA) - Removable SSD for data security - Specialized measurement applications (radar, EMC, semiconductor testing, etc.) |
Note: Delivery information typically includes delivery times, shipping methods, packaging, etc., which may vary depending on the seller and the location of purchase.
The N9030B has a base frequency coverage from 2 Hz to 50 GHz, which can be extended up to 110 GHz using compatible Keysight smart mixers.
The analyzer supports a standard real-time analysis bandwidth of up to 510 MHz, and supports gap-free streaming transmission up to 255 MHz.
Yes, with the optional upgrade to Real-Time Spectrum Analysis (RTSA) functionality, the instrument delivers 510 MHz real-time bandwidth to achieve 100% capture probability for microsecond-level transient signals.
It features built-in support for AM/FM/PM analog modulation and QAM digital modulation (up to 4096-QAM). It also supports dedicated applications for 5G NR, Wi-Fi 7, radar signal analysis, and semiconductor testing.
Data security and portability are supported via configurable large-capacity memory, optional removable solid-state drives (SSDs), and specialized encryption features.
No, the Keysight N9030B operates on external AC power and does not contain a built-in battery pack.
