Classified as a 353 series pulse solenoid valve, this is an electrically piloted diaphragm valve.
Interface size G1, bore diameter 32mm, valve body material aluminium, sealing material nitrile rubber (NBR), flow coefficient Kv 20m³/h, operating medium air, operating voltage 24VDC, minimum operating pressure 2bar, maximum operating pressure 8.5bar.
This pulse valve series is specifically engineered for dust extraction equipment applications. It delivers high flow rates with rapid open/close switching, ensuring reliable and economical operation. Its integrated spun-fit connection facilitates swift, hassle-free installation without requiring threaded pipes. Additionally, it incorporates a silencer to reduce noise levels and prevent foreign particles from entering the valve.
| Valve Actuation | Solenoid, Air Pilot, Air Operated |
| Body Material | Aluminum |
| Media | Air |
| Port Type | NPTF, G-Thread, Quick Mount Clamp Connection |
| Function | 2 way - 2/2 Normally Closed |
| Flow | From 10 to 20 Cv, from 35 to 57 Cv, from 60 to 140 Cv |
| Voltage | 24 AC, 110 AC, 115 AC, 120 AC, 208 AC, 220 AC, 230 AC, 240 AC, 440 AC, 480 AC | 50, 60 Hz | 24V DC | other on request |
| Operating Environment | Hazardous, Indoor, Outdoor |
| Standards / Regulations | Class I Div 1, Class I Div 2, Class II Div 1, Class II Div 2, Type 1, Type 2, Type 3, Type 3R, Type 3S, Type 4, Type 4X, Type 6, Type 6P, Type 7, Type 9, UL, CSA, ATEX Zone 1-21, ATEX Zone 2-22 |
| Product Weight | 1.81 lbs |
| Coil Class | FI |
| Coil Number | 400127-642 |
| Watt Rating | 2 W |
| Item Status | Active |
| Carton Note | 1 X 1-1/4 2NC ALUM 22/F DC |
| Temperature | -40°F to 140°F, -4°F to 284°F |
