At its core, the S67-Y 956271000 leverages Class 1 laser technology (eye-safe, per IEC 60825-1), ensuring safe operation in human-centric industrial spaces while delivering exceptional measurement accuracy:

• Measurement Range: Typically covers a distance span of 0.1 m to 10 m (varies slightly by target reflectivity; e.g., higher accuracy for white/light-colored targets, stable performance for dark targets with ≥10% reflectivity). This range makes it suitable for both short-range and mid-range applications.
• Accuracy & Resolution: Boasts high precision with a typical accuracy of ±2 mm (at 1 m distance) and a resolution of 0.1 mm, ensuring it captures even minute position variations.
• Response Time: Features a fast response time (typically ≤10 ms), enabling real-time data feedback for high-speed automation.

Engineered for harsh industrial conditions, the S67-Y 956271000 prioritizes resilience against physical stress, contaminants, and temperature fluctuations:

• Housing & Protection: Constructed with a rugged, compact metal or high-grade plastic housing, rated IP67 (per IEC 60529). This rating ensures full dust tightness and protection against temporary submersion in water.
• Temperature Resistance: Operates reliably across a wide temperature range of -25 °C to +55 °C, adapting to cold storage facilities or warm industrial zones.
• Immunity to Interference: Equipped with EMC (Electromagnetic Compatibility) protection, minimizing signal disruption from nearby motors, inverters, or other electrical equipment.

The sensor is designed for easy setup and seamless integration into existing automation systems, reducing deployment time and complexity:

• Output Interfaces: Supports multiple industrial output types including Analog outputs (4–20 mA or 0–10 V DC) and Digital outputs (2 x PNP/NPN configurable outputs).
• Setup Methods: Offers user-friendly configuration via built-in teach buttons for quick on-site calibration or specialized alignment software for advanced configuration.
• Mounting Options: Compact, lightweight design supports bracket mounting or direct surface mounting, fitting into space-constrained areas.

The S67-Y 956271000 is versatile across industries, addressing key automation needs for distance and position monitoring:

• Automotive Manufacturing: Measuring the position of car body panels during assembly or monitoring the height of robotic arms in painting stations.
• Logistics & Material Handling: Detecting the height of pallets/boxes on conveyors or verifying the fill level of bulk material bins.
• Packaging Machinery: Monitoring the distance of film rolls in packaging lines or ensuring consistent spacing between packages.
• Machine Tooling: Measuring the travel distance of machine slides or tool heads.

Dimension: 20*65*50mm

Weight: 0.3kg
