Best Megger MFT1711 MFT1700 Series Multifunction Tester Manufacturer, Exporter

The MFT1700 series is a range of instruments for testing low-voltage electrical equipment compliant with BS7671. They provide all the tests required to complete the necessary electrical certifications for industrial, commercial, and domestic fixed wiring installations.

The MFT1711, an entry-level 18th edition tester, offers CAT IV, three- and two-wire non-tripping circuit testing, along with resistance and fault current display, frequency measurement, and the largest, brightest, and clearest display on the market. It now includes a 1 kV insulation test range, automatic RCD testing, 10 mA RCD, programmable (VAR) RCD, ZMAX, and true RMS voltage measurement.

Send Inquiry

Product Description

Product Overview

The Megger MFT1711 is a versatile installation tester and the entry-level model in the Megger MFT series, suitable for testing all single-phase domestic and commercial electrical equipment.

Safety Standards Compliant

Meets IEC 61010 CAT IV 300V rating. It can safely test any part of a low-voltage electrical system up to the power transformer, and is built to withstand accidental misoperation and voltage transients.

High Protection

The rubber-encased housing is IP54 rated for dust and water resistance, making it suitable for use in a variety of harsh environments.

Easy Operation

Ergonomic design allows operation while held, on the floor, on a ladder, or worn around the neck. Settings are easily programmed using two color-coded rotary dials, with dual test and lock buttons for both right and left-handed users.

Rich Functionality

Continuity testing (200mA) with adjustable beeper; insulation testing (250V, 500V, 1000V); loop testing (2-wire, 3-wire, anti-trip); RCD testing (ramp, manual, auto from 10 to 500mA); and accurate TRMS voltage/frequency measurement.

Clear Display

Featuring a large, clear backlit display, results are shown on a patented digital/analog arc to indicate fluctuating readings, while a dual digital readout displays precise critical measurements.

Wide Range of Applications

Complies with BS 7671 standards, providing all necessary testing requirements for the electrical certification of industrial, commercial, and domestic fixed wiring installations.

Specifications

Parameter	Specification
Model	Megger MFT1711
Safety Rating	IEC 61010 CAT IV 300V
Protection Class	IP54
Continuity Testing	- Test current: 200mA (for R1+R2 and R2 tests) - Buzzer threshold: Adjustable
Insulation Resistance Testing	- Test voltages: 250V, 500V, 1000V
Loop Testing	- Test options: 2-wire and 3-wire - Anti-trip function (patented) - Displays PSCC/PFC and loop test results in series
RCD Testing	- Test types: Ramp, manual (0.5x, 1x, 5x), automatic - RCD ratings: 10mA, 30mA, 100mA, 300mA, 500mA AC, A, S, programmable
Voltage & Frequency Measurement	- True RMS voltage measurement - Frequency measurement capability
Display	Large backlit display with patented digital/analog arc (for fluctuating readings) and dual digital readouts
Dimensions	235mm (length) × 85mm (width) × 150mm (height)
Weight	1kg (including batteries, excluding carrying case)
Battery Type	AA alkaline batteries
Compliance	BS 7671
Operating Temperature Range	-10°C to +50°C
Storage Temperature Range	-25°C to +70°C

Megger MFT1711 MFT1700 Series Multifunction Tester Features

Two and three wire non-trip loop testing for fast, repeatable results.
Large bright LCD display showing dual parameters - loop resistance and fault current, insulation resistance and test voltage.
Phase rotation indication for verification of rotating machinery.
3-phase RCD testing for industrial applications with no earth.
3-terminal earth test for electrode resistance measurement.
On-board data storage and Bluetooth® download.

Delivery & Packaging Information

Dimensions:

235 * 85 * 150 mm

Weight:

1kg (including batteries, excluding case)

Battery Type:

AA alkaline

Delivery information typically includes delivery times, shipping methods, packaging, etc., which may vary depending on the seller and the location of purchase.

Manuals & Resources

Megger MFT1711 Multifunction Tester datasheet.pdf

Download Datasheet

Frequently Asked Questions (FAQ)

What safety rating does the Megger MFT1711 have?

The Megger MFT1711 complies with the IEC 61010 CAT IV 300V safety standard, allowing it to safely test low-voltage systems up to the power transformer.

Can the Megger MFT1711 be used in harsh outdoor conditions?

Yes, the device is housed in a robust rubber-encased shell with an IP54 protection rating, which ensures high resistance to dust and water splashes.

What testing options are available for loop testing?

It offers both 2-wire and 3-wire non-trip loop testing configurations. It also features a patented anti-trip system and can display loop test results alongside PSCC/PFC.

What insulation resistance test voltages are supported?

The tester supports three selectable test voltages for insulation resistance: 250V, 500V, and 1000V.

What type of display does the tester use?

It features a large backlit LCD display incorporating a patented digital/analog arc to visualize fluctuating readings, combined with a dual digital readout for critical measurements.

What are the weight and power source specifications of this model?

The unit weighs approximately 1kg (including batteries but excluding the carrying case) and is powered by standard AA alkaline batteries.
